G e n e r a t o r

MJK SERIES 35-82 kVA

TECHNICAL S PECIF ICA TIONS

GENERATOR GROUP
MODEL MJK0035 MJK0050 MJK0055 MJK0070 MJK0082
kVA 35 50 55 70 82
Stand By Power
kW 28 40 44 56 65
kVA 30 47 52 72 82
Prime Power
kW 24 38 42 58 66
DIESEL ENGINE
BRAND KOFO
Model MN4100DS-30 MN4105DS-38 MN4100ZDS MN4105ZDS MN4105ZLDS
Engine Power - Stand By kW 33 42 44 58 68
Engine Power - Prime kW 30 38 42 56 66
Engine Speed (rpm) 1500 1500 1500 1500 1500
Number of Cylinder 4 - In Line 4 - In Line 4 - In Line 4 - In Line 4 - In Line
Displacement (lt) 3.61 4.15 3.61 4.15 4.15
Bore x Stroke (mm) 100x115 105x120 100x115 105x120 105x120
Compression Rate 17:1 17:1 17:1 17:1 17:1
Governor Type Electronic/Mechanic Electronic/Mechanic Electronic/Mechanic Electronic/Mechanic Electronic/Mechanic
46
Induction Natural Natural TurboCharged TurboCharged TurboCharged-Intercooler
Combustion System Direct Injection Direct Injection Direct Injection Direct Injection Direct Injection
Cooling System Water Cooled Water Cooled Water Cooled Water Cooled Water Cooled
Lubrication Oil Capacity (lt) 13 13 13 13 13
Coolant Capacity (lt) 16,0 17 16,0 18 18
Fuel Tank Capacity (lt) 235 230 230 225 225
Fuel 100% of Prime Power 5,7 9,2 8,3 11,9 13,4
Consumption 75% of Prime Power 4,3 6,9 6,3 8,6 10,1
lt / h
50% of Prime Power 2,2 3,5 3,1 4,3 5
ALTERNATOR
Output Voltage (V) 400/230
Power Factor 0.8
Number of Poles 4
Frequency (Hz) 50
Voltage Regulation ±%0,5
Connection Type Star
DIMENSIONS & WEIGHT
Canopy Dimensions mm (WxDxH) 1000x2300x1700 1000x2300x1700 1000x2300x1700 1050x2700x1830 1050x2700x1830
Canopy Weight kg 900 1030 1010 1130 1160
Open Dimensions mm (WxDxH) 1000x1750x1450 1000x1750x1450 1000x1750x1450 1050x2090x1650 1050x2090x1650
Open Weight kg 700 780 820 860 890

Aytemiz-Makelsan reserves the right to make changes in model, specification, color, equipment and accessories without prior notice.
N/A: These dimensions and weights may change depending upon the characteristics of the project.
