G e n e r a t o r

MJS SERIES 500-700 kVA

TECHNICAL S PECIF ICA TIONS

GENERATOR GROUP
MODEL MJS0500 MJS0550 MJS0570 MJS0630 MJS0700
kVA 500 550 570 630 700
Stand By Power
kW 400 440 456 504 560
kVA 455 500 518.2 572.7 636
Prime Power
kW 364 400 414.5 458.2 509
DIESEL ENGINE
BRAND SHANGHAI DONGFENG
Model SMG258TAD45 SMG258TAD46 SMG258TAD51 SMG266TAD56 SMG266TAD63
Engine Power - Stand By kW 450 560 510 565 630
Engine Power - Prime kW 409 418 464 514 573
Engine Speed (rpm) 1500 1500 1500 1500 1500
Number of Cylinder 6 - In Line 6 - In Line 12 - V Type 12 - V Type 12 - V Type
Displacement (lt) 14.2 14.8 25.8 25.8 25.8
Bore x Stroke (mm) 135x165 138x168 135x150 135x160 135x150
Compression Rate 15.5:1 16:1 16:1 16:1 16:1
Governor Type Electronic Electronic Electronic Electronic Electronic
18
Induction TurboCharged-Intercooler TurboCharged-Intercooler TurboCharged-Intercooler TurboCharged-Intercooler TurboCharged-Intercooler
Combustion System Direct Injection Direct Injection Direct Injection Direct Injection Direct Injection
Cooling System Water Cooled Water Cooled Water Cooled Water Cooled Water Cooled
Lubrication Oil Capacity (lt) 48 48 60 60 65
Coolant Capacity (lt) 88 88 108 108 108
Fuel Tank Capacity (lt) 457 548 548 1003 1003
Fuel 100% of Prime Power 76,4 84,0 87,0 96,2 106,9
Consumption 75% of Prime Power 57,3 63,0 65,3 72,2 80,2
lt / h
50% of Prime Power 38,2 42,0 43,5 48,1 53,4
ALTERNATOR
Output Voltage (V) 400/230
Power Factor 0.8
Number of Poles 4
Frequency (Hz) 50
Voltage Regulation ±%0,5
Connection Type Star
DIMENSIONS & WEIGHT
Canopy Dimensions mm (WxDxH) 1600x3700x2200 1750x3700x2120 2100x4800x2330 2100x4800x2330 2100x4800x2330
Canopy Weight kg 3700 3750 5300 5450 5350
Open Dimensions mm (WxDxH) 1600x3200x2000 1750x3504x2000 2100x4000x2200 2100x4000x2200 2100x4000x2200
Open Weight kg 3200 3250 4480 4550 4775

Aytemiz-Makelsan reserves the right to make changes in model, specification, color, equipment and accessories without prior notice.
N/A: These dimensions and weights may change depending upon the characteristics of the project.
