G e n e r a t o r

MJB SERIES 1900-2750 kVA

TECHNICAL S PECIF ICA TIONS

GENERATOR GROUP
MODEL MJB1900 MJB2000 MJB2250 MJB2550 MJB2750
kVA 1900 2000 2250 2550 2750
Stand By Power
kW 1520 1600 1800 2040 2200
kVA 1727.2 1818.2 2045.4 2318.2 2500
Prime Power
kW 1381.2 1454.5 1636.3 1854.5 2000
DIESEL ENGINE
BRAND BAUDOUIN
Model 16M33G1900/5 16M33G2000/5 16M33G2250/5 12M55G2550/5 12M55G2750/5
Engine Power - Stand By kW 1650 1800 1980 2210 2450
Engine Power - Prime kW 1530 1620 1800 1985 2200
Engine Speed (rpm) 1500 1500 1500 1500 1500
Number of Cylinder 16 - V Type 16 - V Type 16 - V Type 12 - V Type 12 - V Type
Displacement (lt) 52.3 52.3 52.3 65.65 65.65
Bore x Stroke (mm) 150x185 150x185 150x185 180x215 180x215
Compression Rate 15:1 15:1 14:1 16.5:1 16.5:1
Governor Type ECU ECU ECU ECU ECU
16
Induction TurboCharged-Aftercooler TurboCharged-Aftercooler TurboCharged-Aftercooler TurboCharged-Aftercooler TurboCharged-Aftercooler
Combustion System Direct Injection Direct Injection Direct Injection Direct Injection Direct Injection
Cooling System Water Cooled Water Cooled Water Cooled Water Cooled Water Cooled
Lubrication Oil Capacity (lt) 171 171 171 560 560
Coolant Capacity (lt) 400 400 412 306 306
Fuel Tank Capacity (lt) N/A N/A N/A N/A N/A
Fuel 100% of Prime Power N/A N/A N/A N/A N/A
Consumption 75% of Prime Power N/A N/A N/A N/A N/A
lt / h
50% of Prime Power N/A N/A N/A N/A N/A
ALTERNATOR
Output Voltage (V) 400/230
Power Factor 0.8
Number of Poles 4
Frequency (Hz) 50
Voltage Regulation ±%0,5
Connection Type Star
DIMENSIONS & WEIGHT
Canopy Dimensions mm (WxDxH) N/A N/A N/A N/A N/A
Canopy Weight kg N/A N/A N/A N/A N/A
Open Dimensions mm (WxDxH) N/A N/A N/A N/A N/A
Open Weight kg N/A N/A N/A N/A N/A

Aytemiz-Makelsan reserves the right to make changes in model, specification, color, equipment and accessories without prior notice.
N/A: These dimensions and weights may change depending upon the characteristics of the project.
