G e n e r a t o r G e n e r a t o r

MJW SERIES 460-640 kVA MJW SERIES 715-1125 kVA

TECHNICAL S PECIF ICA TIONS TECHNICAL S PECIF ICA TIONS

GENERATOR GROUP GENERATOR GROUP
MODEL MJW0460 MJW0500 MJW0605 MJW640 MODEL MJW0715 MJW0825 MJW1000 MJW1125
kVA 460 500 605 640 kVA 715 825 1000 1125
Stand By Power Stand By Power
kW 368 400 484 512 kW 572 660 800 900
kVA 418.2 454.5 550 581.9 kVA 650 750 909 1023
Prime Power Prime Power
kW 334.5 413.2 44 0 465.5 kW 520 600 727.3 819
DIESEL ENGINE DIESEL ENGINE
BRAND SHANGHAI QN BRAND SHANGHAI QN
Model QN13H435 QN13H516 QN26H571 QN26H612 Model QN28H748 QN28H843 QN28H960 QN28H1100
Engine Power - Stand By kW 375 450 560 510 Engine Power - Stand By kW 630 720 840 936
Engine Power - Prime kW 341 409 418 464 Engine Power - Prime kW 573 655 764 851
Engine Speed (rpm) 1500 1500 1500 1500 Engine Speed (rpm) 1500 1500 1500 1500
Number of Cylinder 6 - In Line 6 - In Line 12 - V Type 12 - V Type Number of Cylinder 12 - V Type 12 - V Type 12 - V Type 12 - V Type
Displacement (lt) 14.2 14.2 14.8 25.8 Displacement (lt) 26.6 26.6 28.3 28.3
Bore x Stroke (mm) 135x165 135x165 138x168 135x150 Bore x Stroke (mm) 135x158 135x158 138x165 138x165
Compression Rate 15.5:1 15.5:1 16:1 16:1 Compression Rate 16:1 16:1 16:1 15.4:1
Governor Type Electronic Electronic Electronic Electronic Governor Type Electronic Electronic Electronic Electronic
Induction TurboCharged-Intercooler TurboCharged-Intercooler TurboCharged-Intercooler TurboCharged-Intercooler Induction TurboCharged-Intercooler TurboCharged-Intercooler TurboCharged-Intercooler TurboCharged-Intercooler 39
Combustion System Direct Injection Direct Injection Direct Injection Direct Injection Combustion System Direct Injection Direct Injection Direct Injection Direct Injection
Cooling System Water Cooled Water Cooled Water Cooled Water Cooled Cooling System Water Cooled Water Cooled Water Cooled Water Cooled
Lubrication Oil Capacity (lt) 41 41 65 65 Lubrication Oil Capacity (lt) 65 65 65 65
Coolant Capacity (lt) 80 80 147 147 Coolant Capacity (lt) 147 147 147 147
Fuel Tank Capacity (lt) 491 885 885 885 Fuel Tank Capacity (lt) 885 885 885 1100
Fuel 100% of Prime Power 81 91 105 126 Fuel 100% of Prime Power 141 162 162 162
Consumption 75% of Prime Power 60 69 80 95 Consumption 75% of Prime Power 107 113 113 113
lt / h lt / h
50% of Prime Power 41 48 55 66 50% of Prime Power 74 77 77 77
ALTERNATOR ALTERNATOR
Output Voltage (V) 400/230 Output Voltage (V) 400/230
Power Factor 0.8 Power Factor 0.8
Number of Poles 4 Number of Poles 4
Frequency (Hz) 50 Frequency (Hz) 50
Voltage Regulation ±%0,5 Voltage Regulation ±%0,5
Connection Type Star Connection Type Star
DIMENSIONS & WEIGHT DIMENSIONS & WEIGHT
Canopy Dimensions mm (WxDxH) 1550x3500x2450 1550x3500x2450 1800x4800x2700 1800x4000x2700 Canopy Dimensions mm (WxDxH) 2000x4000x2700 2000x4000x2700 2400x5100x2800 2400x5100x2800
Canopy Weight kg 3460 3700 5700 5300 Canopy Weight kg 5100 5400 7500 7500
Open Dimensions mm (WxDxH) 1550x3500x2000 1550x3500x2000 1800x4000x2200 1800x4000x2200 Open Dimensions mm (WxDxH) 2000x4000x2200 2000x4000x2200 2400x5100x2300 2400x5100x2300
Open Weight kg 3050 3250 4900 4500 Open Weight kg 4250 4560 6000 6000

Aytemiz-Makelsan reserves the right to make changes in model, specification, color, equipment and accessories without prior notice. Aytemiz-Makelsan reserves the right to make changes in model, specification, color, equipment and accessories without prior notice.
N/A: These dimensions and weights may change depending upon the characteristics of the project. N/A: These dimensions and weights may change depending upon the characteristics of the project.
