G e n e r a t o r

MJL SERIES 18-44 kVA

TECHNICAL S PECIF ICA TIONS

GENERATOR GROUP
MODEL MJL0018 MJL0025 MJL0028 MJL0035 MJL0044
kVA 18 25 28 35 44
Stand By Power
kW 14 20 22 28 35
kVA 16 23 25 32 40
Prime Power
kW 13 18 20 25 32
DIESEL ENGINE
BRAND LISTER PETTER
Model SA423G1 SA427G1 SA430G1 SA432G1 SA432G2
Engine Power - Stand By kW 18 24 30 35 44
Engine Power - Prime kW 16 22 27 32 39
Engine Speed (rpm) 1500 1500 1500 1500 1500
Number of Cylinder 4 - In Line 4 - In Line 4 - In Line 4 - In Line 4 - In Line
Displacement (lt) 2.3 2.7 3.0 3.2 3.2
Bore x Stroke (mm) 85x100 90x105 95x105 98x105 98x105
Compression Rate 18.0:1 18.5:1 18.5:1 18.5:1 18.5:1
Governor Type Electronic Electronic Electronic Electronic Electronic
28
Induction Natural Natural Natural Natural TurboCharged
Combustion System Direct Injection Direct Injection Direct Injection Direct Injection Direct Injection
Cooling System Water Cooled Water Cooled Water Cooled Water Cooled Water Cooled
Lubrication Oil Capacity (lt) 6 8 8 8 8
Coolant Capacity (lt) 9.1 9.8 11.4 11.4 13.2
Fuel Tank Capacity (lt) 78.2 78.2 78.2 113 113
Fuel 100% of Prime Power 4.9 5.8 7.3 8.5 9.7
Consumption 75% of Prime Power 3.85 4.25 5.5 6.15 7.3
lt / h
50% of Prime Power 2.75 3 3.9 4.35 5.2
ALTERNATOR
Output Voltage (V) 400/230
Power Factor 0.8
Number of Poles 4
Frequency (Hz) 50
Voltage Regulation ±%0,5
Connection Type Star
DIMENSIONS & WEIGHT
Canopy Dimensions mm (WxDxH) 900x2000x1310 900x2000x1310 900x2000x1310 1000x2300x1715 1000x2300x1715
Canopy Weight kg 750 850 905 925 945
Open Dimensions mm (WxDxH) 900x1500x1100 900x1500x1100 900x1500x1100 1000x1750x1450 1000x1750x1450
Open Weight kg 600 700 755 765 785

Aytemiz-Makelsan reserves the right to make changes in model, specification, color, equipment and accessories without prior notice.
N/A: These dimensions and weights may change depending upon the characteristics of the project.
