G  e  n  e  r  a  t  o  r  G  e  n  e  r  a  t  o  r

 MJR SERIES 35-82 kVA  MJR SERIES 94-150 kVA



 TECHNICAL  S PECIF ICA TIONS  TECHNICAL  S PECIF ICA TIONS



 GENERATOR GROUP  GENERATOR GROUP
 MODEL  MJR0035  MJR0050  MJR0055  MJR0070  MJR0082  MODEL  MJR0094  MJR0110  MJR0110  MJR0125        MJR0150
 kVA  35  50  55  70  82    kVA          94              110            110             125             150
 Stand By Power  Stand By Power
 kW  28  40  44  56  65.6   kW           75.2             88             88             100             120
 kVA  32  45.5  50  63.6  75  kVA        85.4            100            100             113.6          136.4
 Prime Power  Prime Power
 kW  25.6  36.3  40  50.9  60  kW        68.3             80             80             90.9            109
 DIESEL ENGINE  DIESEL ENGINE
 BRAND  RICARDO  BRAND                                                RICARDO
 Model  K4100D  K4100ZD  K4102ZD  D4105ZD/ZH4105ZD D4105IZLD/ZH4105IZLD  Model  R4105IZLD  R4110IZLD  R6105ZD  R6105ZD  R6105AZLD
 Engine Power - Stand By  kW  33  44  48  62  73  Engine Power - Stand By  kW  83  92  92  92           121
 Engine Power - Prime  kW  30.1  40  44  56  66  Engine Power - Prime  kW  75  84  84    84             110
 Engine Speed (rpm)  1500  1500  1500  1500  1500  Engine Speed (rpm)  1500  1500  1500  1500           1500
 Number of Cylinder  4 - In Line  4 - In Line  4 - In Line  4 - In Line  4 - In Line  Number of Cylinder  4 - In Line  4 - In Line  6 - In Line  6 - In Line  6 - In Line
 Displacement (lt)  3.61  3.61  3.61  3.61  4.4  Displacement (lt)  4.4  4.4  6.49      6.49            6.75
 Bore x Stroke (mm)  100x115  100x115  102x115  105x115  105x125/105x115  Bore x Stroke (mm)  105x130  105x130  105x130  105x130  105x130
 Compression Rate  17:1  17:1  17:1  17:1  16:1/17:1  Compression Rate  16:1  16:1  16:1  16:1          16:1
 Governor Type  Mechanic/Electronic  Mechanic/Electronic  Mechanic/Electronic  Mechanic/Electronic  Mechanic/Electronic  Governor Type  Mechanic/Electronic  Mechanic/Electronic  Mechanic/Electronic  Mechanic/Electronic  Mechanic/Electronic
 Induction  Natural  TurboCharged  TurboCharged  TurboCharged  TurboCharged-Intercooler  Induction  TurboCharged  TurboCharged  TurboCharged  TurboCharged  TurboCharged  35
 Combustion System  Direct Injection  Direct Injection  Direct Injection  Direct Injection  Direct Injection  Combustion System  Direct Injection  Direct Injection  Direct Injection  Direct Injection  Direct Injection
 Cooling System  Water Cooled  Water Cooled  Water Cooled  Water Cooled  Water Cooled  Cooling System  Water Cooled  Water Cooled  Water Cooled  Water Cooled  Water Cooled
 Lubrication Oil Capacity (lt)  13  13  13  13  13  Lubrication Oil Capacity (lt)  13  13  16  16       16
 Coolant Capacity (lt)  13  13  13  13  16/13  Coolant Capacity (lt)  18  18  23         23             25
 Fuel Tank Capacity (lt)  113  113  113  187  187  Fuel Tank Capacity (lt)  187  187  300  300          300
 Fuel  100% of Prime Power  6.6  9.1  10.1  12.8  15.0  Fuel  100% of Prime Power  16.3  19.1  17.9  20.4  24.4
 Consumption  75% of Prime Power  4.9  6.9  7.5  9.6  11.3  Consumption  75% of Prime Power  12.3  14.3  13.4  15.3  18.3
 lt / h  lt / h
 50% of Prime Power  3.3  4.6  5.0  6.4  7.5  50% of Prime Power  8.2  9.6  9.0         10.2            12.2
 ALTERNATOR  ALTERNATOR
 Output Voltage (V)  400/230  Output Voltage (V)                       400/230
 Power Factor  0.8  Power Factor                                         0.8
 Number of Poles  4  Number of Poles                                     4
 Frequency (Hz)  50  Frequency (Hz)                                      50
 Voltage Regulation  ±%0,5  Voltage Regulation                         ±%0,5
 Connection Type  Star  Connection Type                                 Star
 DIMENSIONS & WEIGHT  DIMENSIONS & WEIGHT
 Canopy Dimensions mm (WxDxH)  1000x2300x1700  1000x2300x1700  1000x2300x1700  1050x2700x1830  1050x2700x1830  Canopy Dimensions mm (WxDxH)  1050x2700x1830  1050x2700x1830  1050x3000x2130  1050x3000x2130  1050x3000x2130
 Canopy Weight  kg  900  1030  1010  1130  1160  Canopy Weight  kg  1320  1325  1450    1450            1655
 Open Dimensions  mm (WxDxH)  1000x1750x1450  1000x1750x1450  1000x1750x1450  1050x2090x1650  1050x2090x1650  Open Dimensions  mm (WxDxH)  1050x2090x1650  1050x2090x1650  1050x2400x1750  1050x2400x1750  1050x2400x1750
 Open Weight  kg  700  780  820  860  890  Open Weight  kg  980  1050   1160            1300            1400

 Aytemiz-Makelsan reserves the right to make changes in model, specification, color, equipment and accessories without prior notice.  Aytemiz-Makelsan reserves the right to make changes in model, specification, color, equipment and accessories without prior notice.
 N/A: These dimensions and weights may change depending upon the characteristics of the project.  N/A: These dimensions and weights may change depending upon the characteristics of the project.
